2N7002DW
Shenzhen Slkormicro Semicon Co., Ltd.
Package: Cut Tape (CT)
Description: 60V 115MA 7.5@10V,500MA 200MW 2.
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Grade | - |
|---|---|
| Technology | MOSFET (Metal Oxide) |
| FET Feature | - |
| Part Status | Active |
| Power - Max | 200mW (Ta) |
| Configuration | 2 N-Channel (Dual) |
| Mounting Type | Surface Mount |
| Qualification | - |
| Package / Case | 6-TSSOP, SC-88, SOT-363 |
| Vgs(th) (Max) @ Id | 2.5V @ 250μA |
| Operating Temperature | 150°C (TJ) |
| Rds On (Max) @ Id, Vgs | 7.5Ohm @ 500mA, 10V |
| Supplier Device Package | SOT-363 |
| Gate Charge (Qg) (Max) @ Vgs | - |
| Drain to Source Voltage (Vdss) | 60V |
| Input Capacitance (Ciss) (Max) @ Vds | 50pF @ 25V |
| Current - Continuous Drain (Id) @ 25°C | 115mA (Ta) |
