AFGB40T65RQDN
onsemi
Package: Cut Tape (CT)
Description: IGBT FIELD STOP 650V 68A TO-263
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| IGBT Type | Field Stop |
|---|---|
| Input Type | Standard |
| Gate Charge | 51 nC |
| Part Status | Active |
| Power - Max | 339.37 W |
| Mounting Type | Surface Mount |
| Package / Case | TO-263-3, D2PAK (2 Leads + Tab), TO-263AB |
| Test Condition | 400V, 20A, 3Ohm, 15V |
| Switching Energy | 470μJ (on), 420μJ (off) |
| Td (on/off) @ 25°C | 21ns/77ns |
| Operating Temperature | -55°C ~ 175°C (TJ) |
| Supplier Device Package | TO-263 (D2PAK) |
| Vce(on) (Max) @ Vge, Ic | 1.82V @ 15V, 40A |
| Reverse Recovery Time (trr) | 52 ns |
| Current - Collector (Ic) (Max) | 68 A |
| Current - Collector Pulsed (Icm) | 160 A |
| Voltage - Collector Emitter Breakdown (Max) | 650 V |
