AOK40B120N1
Alpha & Omega Semiconductor Inc.
Package: Tube
Description: IGBT 1200V 80A TO-247
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| IGBT Type | - |
|---|---|
| Input Type | Standard |
| Gate Charge | 100 nC |
| Part Status | Active |
| Power - Max | 600 W |
| Mounting Type | Through Hole |
| Package / Case | TO-247-3 |
| Test Condition | 600V, 40A, 7.5Ohm, 15V |
| Switching Energy | 3.4mJ (on), 1.4mJ (off) |
| Td (on/off) @ 25°C | 57ns/146ns |
| Operating Temperature | -55°C ~ 175°C (TJ) |
| Supplier Device Package | TO-247 |
| Vce(on) (Max) @ Vge, Ic | 2.5V @ 15V, 40A |
| Reverse Recovery Time (trr) | 300 ns |
| Current - Collector (Ic) (Max) | 80 A |
| Current - Collector Pulsed (Icm) | 160 A |
| Voltage - Collector Emitter Breakdown (Max) | 1200 V |
