AOT8B65M3
Alpha & Omega Semiconductor Inc.
Package: Tape & Reel (TR)
Description: IGBT 650V 16A TO-220
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Grade | - |
|---|---|
| IGBT Type | - |
| Input Type | Standard |
| Gate Charge | 14 nC |
| Part Status | Active |
| Power - Max | 83 W |
| Mounting Type | Through Hole |
| Qualification | - |
| Package / Case | TO-220-3 |
| Test Condition | 400V, 8A, 37.5Ohm, 15V |
| Switching Energy | 130μJ (on), 110μJ (off) |
| Td (on/off) @ 25°C | 6ns/71ns |
| Operating Temperature | -55°C ~ 175°C (TJ) |
| Supplier Device Package | TO-220 |
| Vce(on) (Max) @ Vge, Ic | 2.56V @ 15V, 8A |
| Reverse Recovery Time (trr) | 195 ns |
| Current - Collector (Ic) (Max) | 16 A |
| Current - Collector Pulsed (Icm) | 24 A |
| Voltage - Collector Emitter Breakdown (Max) | 650 V |
