AOTF5B65M2
Alpha & Omega Semiconductor Inc.
Package: Tape & Reel (TR)
Description: IGBT 650V 10A TO-220F
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| IGBT Type | - |
|---|---|
| Input Type | Standard |
| Gate Charge | 14 nC |
| Part Status | Active |
| Power - Max | 25 W |
| Mounting Type | Through Hole |
| Package / Case | TO-220-3 Full Pack |
| Test Condition | 400V, 5A, 60Ohm, 15V |
| Switching Energy | 80μJ (on), 70μJ (off) |
| Td (on/off) @ 25°C | 8.5ns/106ns |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Supplier Device Package | TO-220F |
| Vce(on) (Max) @ Vge, Ic | 1.98V @ 15V, 5A |
| Current - Collector (Ic) (Max) | 10 A |
| Current - Collector Pulsed (Icm) | 15 A |
| Voltage - Collector Emitter Breakdown (Max) | 650 V |
