AOTF8B65MQ1
Alpha & Omega Semiconductor Inc.
Package: Tape & Reel (TR)
Description: IGBT 650V 16A TO-220F
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| IGBT Type | - |
|---|---|
| Input Type | Standard |
| Gate Charge | 22 nC |
| Part Status | Active |
| Power - Max | 30 W |
| Mounting Type | Through Hole |
| Package / Case | TO-220-3 Full Pack |
| Test Condition | 400V, 8A, 37.5Ohm, 15V |
| Switching Energy | 160μJ (on), 110μJ (off) |
| Td (on/off) @ 25°C | 8.5ns/102ns |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Supplier Device Package | TO-220F |
| Vce(on) (Max) @ Vge, Ic | 2.25V @ 15V, 8A |
| Reverse Recovery Time (trr) | 94 ns |
| Current - Collector (Ic) (Max) | 16 A |
| Current - Collector Pulsed (Icm) | 24 A |
| Voltage - Collector Emitter Breakdown (Max) | 650 V |
