APT25GP120BSC15
Microchip Technology
Package: Tube
Description: IGBT PT MOS 7 SIC COMBI 1200 V 2
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Grade | - |
|---|---|
| IGBT Type | PT |
| Input Type | Standard |
| Gate Charge | 110 nC |
| Part Status | Active |
| Power - Max | 417 W |
| Mounting Type | Through Hole |
| Qualification | - |
| Package / Case | TO-247-3 |
| Test Condition | 600V, 25A, 5Ohm, 15V |
| Switching Energy | 560μJ (on), 440μJ (off) |
| Td (on/off) @ 25°C | 12ns/70ns |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Supplier Device Package | TO-247-3 |
| Vce(on) (Max) @ Vge, Ic | - |
| Current - Collector (Ic) (Max) | 69 A |
| Current - Collector Pulsed (Icm) | 90 A |
| Voltage - Collector Emitter Breakdown (Max) | 1200 V |
