APT40GF120JRD
Microchip Technology
Package: Tube
Description: IGBT NPT COMBI 1200V 40A ISOTOP
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Input | Standard |
|---|---|
| IGBT Type | - |
| Part Status | Active |
| Power - Max | 390 W |
| Configuration | Single |
| Mounting Type | Chassis Mount |
| NTC Thermistor | No |
| Package / Case | SOT-227-4, miniBLOC |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Supplier Device Package | SOT-227 (ISOTOP?) |
| Vce(on) (Max) @ Vge, Ic | 3.4V @ 15V, 50A |
| Current - Collector (Ic) (Max) | 60 A |
| Input Capacitance (Cies) @ Vce | 3.45 nF @ 25 V |
| Current - Collector Cutoff (Max) | 500 μA |
| Voltage - Collector Emitter Breakdown (Max) | 1200 V |
