AW2K21AR
ROHM Semiconductor
Package: Cut Tape (CT)
Description: 30V 20A, DUAL NCH+NCH, WLCSP2020
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Grade | - |
|---|---|
| Technology | MOSFET (Metal Oxide) |
| FET Feature | - |
| Part Status | Active |
| Power - Max | 1.6W (Ta) |
| Configuration | 2 N-Channel, Common Source |
| Mounting Type | Surface Mount |
| Qualification | - |
| Package / Case | 22-UFBGA, WLCSP |
| Vgs(th) (Max) @ Id | 2V @ 1mA |
| Operating Temperature | 150°C (TJ) |
| Rds On (Max) @ Id, Vgs | 3mOhm @ 20A, 10V |
| Supplier Device Package | 22-WLCSP (2x2) |
| Gate Charge (Qg) (Max) @ Vgs | 29nC @ 10V |
| Drain to Source Voltage (Vdss) | 30V |
| Input Capacitance (Ciss) (Max) @ Vds | 1350pF @ 10V |
| Current - Continuous Drain (Id) @ 25°C | 20A (Ta) |
