DMC62D2SVQ-13
Diodes Incorporated
Package: Tape & Reel (TR)
Description: MOSFET N/P-CH 60V 0.48A SOT563
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Grade | Automotive |
|---|---|
| Technology | MOSFET (Metal Oxide) |
| FET Feature | - |
| Part Status | Active |
| Power - Max | 500mW (Ta) |
| Configuration | N and P-Channel Complementary |
| Mounting Type | Surface Mount |
| Qualification | AEC-Q101 |
| Package / Case | SOT-563, SOT-666 |
| Vgs(th) (Max) @ Id | 2.5V @ 250μA, 3V @ 250μA |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Rds On (Max) @ Id, Vgs | 1.7Ohm @ 200mA, 10V, 4Ohm @ 200mA, 10V |
| Supplier Device Package | SOT-563 |
| Gate Charge (Qg) (Max) @ Vgs | 1.04nC @ 10V, 1.1nC @ 10V |
| Drain to Source Voltage (Vdss) | 60V |
| Input Capacitance (Ciss) (Max) @ Vds | 41pF @ 30V, 40pF @ 25V |
| Current - Continuous Drain (Id) @ 25°C | 480mA (Ta), 320mA (Ta) |
