DMN52D0UDM-7
Diodes Incorporated
Package: Tape & Reel (TR)
Description: MOSFET 2N-CH 50V 0.41A SOT26
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Grade | - |
|---|---|
| Technology | MOSFET (Metal Oxide) |
| FET Feature | - |
| Part Status | Active |
| Power - Max | 490mW (Ta) |
| Configuration | 2 N-Channel (Dual) |
| Mounting Type | Surface Mount |
| Qualification | - |
| Package / Case | SOT-23-6 |
| Vgs(th) (Max) @ Id | 1V @ 250μA |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Rds On (Max) @ Id, Vgs | 2Ohm @ 50mA, 5V |
| Supplier Device Package | SOT-26 |
| Gate Charge (Qg) (Max) @ Vgs | 1.6nC @ 10V |
| Drain to Source Voltage (Vdss) | 50V |
| Input Capacitance (Ciss) (Max) @ Vds | 42.4pF @ 25V |
| Current - Continuous Drain (Id) @ 25°C | 410mA (Ta) |
