FGY4L160T120SWD
onsemi
Package: Tube
Description: IGBT FS 1200V 200A TO-247-4L
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Grade | - |
|---|---|
| IGBT Type | Field Stop |
| Input Type | Standard |
| Gate Charge | 474 nC |
| Part Status | Active |
| Power - Max | 1500 W |
| Mounting Type | Through Hole |
| Qualification | - |
| Package / Case | TO-247-4 |
| Test Condition | 600V, 160A, 4Ohm, 15V |
| Switching Energy | 4.2mJ (on), 5.9mJ (off) |
| Td (on/off) @ 25°C | 60.8ns/236.8ns |
| Operating Temperature | -55°C ~ 175°C (TJ) |
| Supplier Device Package | TO-247-4L |
| Vce(on) (Max) @ Vge, Ic | 2V @ 15V, 160A |
| Reverse Recovery Time (trr) | 264.1 ns |
| Current - Collector (Ic) (Max) | 200 A |
| Current - Collector Pulsed (Icm) | 640 A |
| Voltage - Collector Emitter Breakdown (Max) | 1200 V |
