FP50R12N2T7PB11BPSA1
Infineon Technologies
Package: Tray
Description: LOW POWER ECONO
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Input | Three Phase Bridge Rectifier |
|---|---|
| IGBT Type | Trench Field Stop |
| Part Status | Active |
| Configuration | Three Phase Inverter with Brake |
| Mounting Type | Chassis Mount |
| NTC Thermistor | Yes |
| Package / Case | Module |
| Operating Temperature | -40°C ~ 175°C (TJ) |
| Supplier Device Package | AG-ECONO2B |
| Vce(on) (Max) @ Vge, Ic | 1.8V @ 15V, 50A |
| Current - Collector (Ic) (Max) | 50 A |
| Input Capacitance (Cies) @ Vce | 11.1 nF @ 25 V |
| Current - Collector Cutoff (Max) | 10 μA |
| Voltage - Collector Emitter Breakdown (Max) | 1200 V |
