FS75R12KE3BPSA1
Infineon Technologies
Package: Tray
Description: LOW POWER ECONO AG-ECONO2B-311
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Input | Standard |
|---|---|
| IGBT Type | - |
| Part Status | Active |
| Power - Max | 350 W |
| Configuration | Full Bridge Inverter |
| Mounting Type | Chassis Mount |
| NTC Thermistor | Yes |
| Package / Case | Module |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Supplier Device Package | AG-ECONO2B |
| Vce(on) (Max) @ Vge, Ic | 2.15V @ 15V, 75A |
| Current - Collector (Ic) (Max) | 105 A |
| Input Capacitance (Cies) @ Vce | 5.3 nF @ 25 V |
| Current - Collector Cutoff (Max) | 5 mA |
| Voltage - Collector Emitter Breakdown (Max) | 1200 V |
