FS75R12W2T7B11BOMA1
Infineon Technologies
Package: Tray
Description: IGBT MOD 1200V 75A
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Input | Standard |
|---|---|
| IGBT Type | Trench Field Stop |
| Part Status | Active |
| Configuration | Full Bridge |
| Mounting Type | Chassis Mount |
| NTC Thermistor | No |
| Package / Case | Module |
| Operating Temperature | -40°C ~ 175°C |
| Supplier Device Package | Module |
| Vce(on) (Max) @ Vge, Ic | 1.55V @ 15V, 75A (Typ) |
| Current - Collector (Ic) (Max) | 65 A |
| Input Capacitance (Cies) @ Vce | 15.1 nF @ 25 V |
| Current - Collector Cutoff (Max) | 13 μA |
| Voltage - Collector Emitter Breakdown (Max) | 1200 V |
