GSFK02002
Good-Ark Semiconductor
Package: Cut Tape (CT)
Description: MOSFET, N-CH, DUAL, 0.75A, 20V,
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Grade | - |
|---|---|
| Technology | MOSFET (Metal Oxide) |
| FET Feature | - |
| Part Status | Active |
| Power - Max | 150mW (Ta) |
| Configuration | 2 N-Channel (Half Bridge) |
| Mounting Type | Surface Mount |
| Qualification | - |
| Package / Case | 6-TSSOP, SC-88, SOT-363 |
| Vgs(th) (Max) @ Id | 1.1V @ 250μA |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Rds On (Max) @ Id, Vgs | 380mOhm @ 650mA, 4.5V |
| Supplier Device Package | SOT-363 |
| Gate Charge (Qg) (Max) @ Vgs | 2nC @ 4.5V |
| Drain to Source Voltage (Vdss) | 20V |
| Input Capacitance (Ciss) (Max) @ Vds | 43pF @ 10V |
| Current - Continuous Drain (Id) @ 25°C | 750mA (Ta) |
