HT8MD5HTB1
ROHM Semiconductor
Package: Cut Tape (CT)
Description: 80V 9.0A/8.5A, DUAL NCH+PCH, HSM
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Grade | - |
|---|---|
| Technology | MOSFET (Metal Oxide) |
| FET Feature | - |
| Part Status | Active |
| Power - Max | 2W (Ta), 13W (Tc) |
| Configuration | N and P-Channel |
| Mounting Type | Surface Mount |
| Qualification | - |
| Package / Case | 8-PowerVDFN |
| Vgs(th) (Max) @ Id | 4V @ 1mA |
| Operating Temperature | 150°C (TJ) |
| Rds On (Max) @ Id, Vgs | 112mOhm @ 3.5A, 10V, 165mOhm @ 3A, 10V |
| Supplier Device Package | 8-HSMT (3.2x3) |
| Gate Charge (Qg) (Max) @ Vgs | 3.1nC @ 10V, 17.2nC @ 10V |
| Drain to Source Voltage (Vdss) | 80V |
| Input Capacitance (Ciss) (Max) @ Vds | 90pF @ 40V, 720pF @ 40V |
| Current - Continuous Drain (Id) @ 25°C | 3.5A (Ta), 9A (Tc), 3A (Ta), 8.5A (Tc) |
