IKN03N60RC2ATMA1
Infineon Technologies
Package: Cut Tape (CT)
Description: IGBT 600V 5.7A SOT223-3
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| IGBT Type | - |
|---|---|
| Input Type | Standard |
| Gate Charge | 18 nC |
| Part Status | Active |
| Power - Max | 6.3 W |
| Mounting Type | Surface Mount |
| Package / Case | TO-261-3 |
| Test Condition | 400V, 3A, 49Ohm, 15V |
| Switching Energy | 62μJ (on), 44μJ (off) |
| Td (on/off) @ 25°C | 7ns/77.5ns |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Supplier Device Package | PG-SOT223-3-1 |
| Vce(on) (Max) @ Vge, Ic | 2.3V @ 15V, 3A |
| Reverse Recovery Time (trr) | 38 ns |
| Current - Collector (Ic) (Max) | 5.7 A |
| Current - Collector Pulsed (Icm) | 9 A |
| Voltage - Collector Emitter Breakdown (Max) | 600 V |
