IXBF55N300
IXYS
Package: Tube
Description: IGBT 3000V 86A ISOPLUS I4-PAC
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| IGBT Type | - |
|---|---|
| Input Type | Standard |
| Gate Charge | 335 nC |
| Part Status | Active |
| Power - Max | 357 W |
| Mounting Type | Through Hole |
| Package / Case | i4-Pac?-5 (3 Leads) |
| Test Condition | - |
| Switching Energy | - |
| Td (on/off) @ 25°C | - |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Supplier Device Package | ISOPLUS i4-PAC? |
| Vce(on) (Max) @ Vge, Ic | 3.2V @ 15V, 55A |
| Reverse Recovery Time (trr) | 1.9 μs |
| Current - Collector (Ic) (Max) | 86 A |
| Current - Collector Pulsed (Icm) | 600 A |
| Voltage - Collector Emitter Breakdown (Max) | 3000 V |
