IXYH120N65A5
IXYS
Package: Tube
Description: IGBT PT 650V 290A TO-247
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| IGBT Type | PT |
|---|---|
| Input Type | Standard |
| Gate Charge | 314 nC |
| Part Status | Active |
| Power - Max | 830 W |
| Mounting Type | Through Hole |
| Package / Case | TO-247-3 |
| Test Condition | 400V, 60A, 3Ohm, 15V |
| Switching Energy | 1.25mJ (on), 3.2mJ (off) |
| Td (on/off) @ 25°C | 45ns/370ns |
| Operating Temperature | -55°C ~ 175°C (TJ) |
| Supplier Device Package | TO-247 (IXTH) |
| Vce(on) (Max) @ Vge, Ic | 1.35V @ 15V, 75A |
| Current - Collector (Ic) (Max) | 290 A |
| Current - Collector Pulsed (Icm) | 790 A |
| Voltage - Collector Emitter Breakdown (Max) | 650 V |
