IXYP60N65A5
IXYS
Package: Tube
Description: IGBT PT 650V 134A TO-220
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| IGBT Type | PT |
|---|---|
| Input Type | Standard |
| Gate Charge | 128 nC |
| Part Status | Active |
| Power - Max | 395 W |
| Mounting Type | Through Hole |
| Package / Case | TO-220-3 |
| Test Condition | 400V, 36A, 5Ohm, 15V |
| Switching Energy | 600μJ (on), 1.45mJ (off) |
| Td (on/off) @ 25°C | 28ns/230ns |
| Operating Temperature | -55°C ~ 175°C (TJ) |
| Supplier Device Package | TO-220 (IXYP) |
| Vce(on) (Max) @ Vge, Ic | 1.35V @ 15V, 36A |
| Current - Collector (Ic) (Max) | 134 A |
| Current - Collector Pulsed (Icm) | 260 A |
| Voltage - Collector Emitter Breakdown (Max) | 650 V |
