MCT06P10HE3-TP
MCC (Micro Commercial Components)
Package: Tape & Reel (TR)
Description: P-CHANNEL MOSFET,SOT-223
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Grade | Automotive |
|---|---|
| FET Type | P-Channel |
| Vgs (Max) | ±20V |
| Technology | MOSFET (Metal Oxide) |
| FET Feature | - |
| Part Status | Active |
| Mounting Type | Surface Mount |
| Qualification | AEC-Q101 |
| Package / Case | TO-261-4, TO-261AA |
| Vgs(th) (Max) @ Id | 2.5V @ 250μA |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Rds On (Max) @ Id, Vgs | 210mOhm @ 6A, 10V |
| Power Dissipation (Max) | 1.9W (Tj) |
| Supplier Device Package | SOT-223 |
| Gate Charge (Qg) (Max) @ Vgs | 24.6 nC @ 10 V |
| Drain to Source Voltage (Vdss) | 100 V |
| Input Capacitance (Ciss) (Max) @ Vds | 1369 pF @ 50 V |
| Drive Voltage (Max Rds On, Min Rds On) | 4.5V, 10V |
| Current - Continuous Drain (Id) @ 25°C | 6A (Ta) |
