MIF600R12C2TL-BP
MCC (Micro Commercial Components)
Package: Bulk
Description: IGBT MOD 1200V 600A 3480W
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Input | Standard |
|---|---|
| IGBT Type | Trench |
| Part Status | Active |
| Power - Max | 3.48 kW |
| Configuration | Half Bridge Inverter |
| Mounting Type | Chassis Mount |
| NTC Thermistor | No |
| Package / Case | Module |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Supplier Device Package | - |
| Vce(on) (Max) @ Vge, Ic | 2.5V @ 15V, 600A |
| Current - Collector (Ic) (Max) | 600 A |
| Input Capacitance (Cies) @ Vce | 101500 pF @ 25 V |
| Current - Collector Cutoff (Max) | 1 mA |
| Voltage - Collector Emitter Breakdown (Max) | 1200 V |
