PJA3401-AU_R1_000A1
Panjit International Inc.
Package: Cut Tape (CT)
Description: 30V P-CHANNEL ENHANCEMENT MODE M
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Grade | Automotive |
|---|---|
| FET Type | P-Channel |
| Vgs (Max) | ±12V |
| Technology | MOSFET (Metal Oxide) |
| FET Feature | - |
| Part Status | Active |
| Mounting Type | Surface Mount |
| Qualification | AEC-Q101 |
| Package / Case | TO-236-3, SC-59, SOT-23-3 |
| Vgs(th) (Max) @ Id | 1.3V @ 250μA |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Rds On (Max) @ Id, Vgs | 72mOhm @ 3.6A, 10V |
| Power Dissipation (Max) | 1.25W (Ta) |
| Supplier Device Package | SOT-23 |
| Gate Charge (Qg) (Max) @ Vgs | 15 nC @ 10 V |
| Drain to Source Voltage (Vdss) | 30 V |
| Input Capacitance (Ciss) (Max) @ Vds | 633 pF @ 15 V |
| Drive Voltage (Max Rds On, Min Rds On) | 2.5V, 10V |
| Current - Continuous Drain (Id) @ 25°C | 3.6A (Ta) |
