QH8ME5TCR
ROHM Semiconductor
Package: Cut Tape (CT)
Description: MOSFET N/P-CH 100V 2A TSMT8
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Grade | - |
|---|---|
| Technology | MOSFET (Metal Oxide) |
| FET Feature | - |
| Part Status | Active |
| Power - Max | 1.1W (Ta) |
| Configuration | N and P-Channel |
| Mounting Type | Surface Mount |
| Qualification | - |
| Package / Case | 8-SMD, Flat Leads |
| Vgs(th) (Max) @ Id | 2.5V @ 1mA |
| Operating Temperature | 150°C (TJ) |
| Rds On (Max) @ Id, Vgs | 202mOhm @ 2A, 10V, 270mOhm @ 2A, 10V |
| Supplier Device Package | TSMT8 |
| Gate Charge (Qg) (Max) @ Vgs | 2.8nC @ 10V, 19.7nC @ 10V |
| Drain to Source Voltage (Vdss) | 100V |
| Input Capacitance (Ciss) (Max) @ Vds | 90pF @ 50V, 590pF @ 50V |
| Current - Continuous Drain (Id) @ 25°C | 2A (Ta) |
