R8011KNZ4C13
ROHM Semiconductor
Package: Cut Tape (CT)
Description: NCH 800V 11A, TO-247AD, HIGH-SPE
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Grade | - |
|---|---|
| FET Type | N-Channel |
| Vgs (Max) | ±20V |
| Technology | MOSFET (Metal Oxide) |
| FET Feature | - |
| Part Status | Active |
| Mounting Type | Through Hole |
| Qualification | - |
| Package / Case | TO-247-3 |
| Vgs(th) (Max) @ Id | 4.5V @ 5.5mA |
| Operating Temperature | 150°C (TJ) |
| Rds On (Max) @ Id, Vgs | 450mOhm @ 5.5A, 10V |
| Power Dissipation (Max) | 139W (Tc) |
| Supplier Device Package | TO-247G |
| Gate Charge (Qg) (Max) @ Vgs | 37 nC @ 10 V |
| Drain to Source Voltage (Vdss) | 800 V |
| Input Capacitance (Ciss) (Max) @ Vds | 1200 pF @ 100 V |
| Drive Voltage (Max Rds On, Min Rds On) | 10V |
| Current - Continuous Drain (Id) @ 25°C | 11A (Ta) |
