RGCL60TS60DGC13
ROHM Semiconductor
Package: Tube
Description: IGBT TRENCH FS 600V 48A TO-247G
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| IGBT Type | Trench Field Stop |
|---|---|
| Input Type | Standard |
| Gate Charge | 68 nC |
| Part Status | Active |
| Power - Max | 111 W |
| Mounting Type | Through Hole |
| Package / Case | TO-247-3 |
| Test Condition | 400V, 30A, 10Ohm, 15V |
| Switching Energy | 770μJ (on), 1.11mJ (off) |
| Td (on/off) @ 25°C | 44ns/186ns |
| Operating Temperature | -40°C ~ 175°C (TJ) |
| Supplier Device Package | TO-247G |
| Vce(on) (Max) @ Vge, Ic | 1.8V @ 15V, 30A |
| Reverse Recovery Time (trr) | 58 ns |
| Current - Collector (Ic) (Max) | 48 A |
| Current - Collector Pulsed (Icm) | 120 A |
| Voltage - Collector Emitter Breakdown (Max) | 600 V |
