RGPR20NL43HRTL
ROHM Semiconductor
Package: Cut Tape (CT)
Description: IGBT 460V 20A TO-263L
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| IGBT Type | - |
|---|---|
| Input Type | Standard |
| Gate Charge | 14 nC |
| Part Status | Active |
| Power - Max | 107 W |
| Mounting Type | Surface Mount |
| Package / Case | TO-263-3, D2PAK (2 Leads + Tab), TO-263AB |
| Test Condition | 300V, 8A, 100Ohm, 5V |
| Switching Energy | - |
| Td (on/off) @ 25°C | 170ns/1.3μs |
| Operating Temperature | -40°C ~ 175°C (TJ) |
| Supplier Device Package | TO-263L |
| Vce(on) (Max) @ Vge, Ic | 2V @ 5V, 10A |
| Current - Collector (Ic) (Max) | 20 A |
| Voltage - Collector Emitter Breakdown (Max) | 460 V |
