RGS00TS65EHRC11
ROHM Semiconductor
Package: Tube
Description: IGBT TRENCH FS 650V 88A TO-247N
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| IGBT Type | Trench Field Stop |
|---|---|
| Input Type | Standard |
| Gate Charge | 58 nC |
| Part Status | Active |
| Power - Max | 326 W |
| Mounting Type | Through Hole |
| Package / Case | TO-247-3 |
| Test Condition | 400V, 50A, 10Ohm, 15V |
| Switching Energy | - |
| Td (on/off) @ 25°C | 36ns/115ns |
| Operating Temperature | -40°C ~ 175°C (TJ) |
| Supplier Device Package | TO-247N |
| Vce(on) (Max) @ Vge, Ic | 2.1V @ 15V, 50A |
| Reverse Recovery Time (trr) | 113 ns |
| Current - Collector (Ic) (Max) | 88 A |
| Current - Collector Pulsed (Icm) | 150 A |
| Voltage - Collector Emitter Breakdown (Max) | 650 V |
