SD103CWH RHG
Taiwan Semiconductor Corporation
Package: Cut Tape (CT)
Description: SOD-123, 20V, 0.35A, SCHOTTKY DI
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Grade | Automotive |
|---|---|
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Technology | Schottky |
| Part Status | Active |
| Mounting Type | Surface Mount |
| Qualification | AEC-Q101 |
| Package / Case | SOD-123 |
| Capacitance @ Vr, F | 50pF @ 0V, 1MHz |
| Supplier Device Package | SOD-123 |
| Reverse Recovery Time (trr) | 10 ns |
| Current - Reverse Leakage @ Vr | 5 μA @ 10 V |
| Voltage - DC Reverse (Vr) (Max) | 14 V |
| Current - Average Rectified (Io) | 350mA |
| Operating Temperature - Junction | -55°C ~ 125°C |
| Voltage - Forward (Vf) (Max) @ If | 600 mV @ 200 mA |
