SF1003G
Taiwan Semiconductor Corporation
Package: Tube
Description: DIODE ARRAY GP 150V 10A TO-220AB
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Grade | - |
|---|---|
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Technology | Standard |
| Part Status | Active |
| Mounting Type | Through Hole |
| Qualification | - |
| Package / Case | TO-220-3 |
| Diode Configuration | 1 Pair Common Cathode |
| Supplier Device Package | TO-220AB |
| Reverse Recovery Time (trr) | 35 ns |
| Current - Reverse Leakage @ Vr | 10 μA @ 150 V |
| Voltage - DC Reverse (Vr) (Max) | 150 V |
| Operating Temperature - Junction | -55°C ~ 150°C |
| Voltage - Forward (Vf) (Max) @ If | 975 mV @ 5 A |
| Current - Average Rectified (Io) (per Diode) | 10A |
