SQJB48EP-T1_JE3
Vishay Siliconix
Package: Cut Tape (CT)
Description: AUTOMOTIVE DUAL N-CHANNEL 40V (
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Grade | - |
|---|---|
| Technology | MOSFET (Metal Oxide) |
| FET Feature | - |
| Part Status | Active |
| Power - Max | 48W (Tc) |
| Configuration | 2 N-Channel (Dual) |
| Mounting Type | Surface Mount |
| Qualification | - |
| Package / Case | PowerPAK? SO-8 Dual |
| Vgs(th) (Max) @ Id | 3.3V @ 250μA |
| Operating Temperature | -55°C ~ 175°C (TJ) |
| Rds On (Max) @ Id, Vgs | 5.2mOhm @ 8A, 10V |
| Supplier Device Package | PowerPAK? SO-8 Dual |
| Gate Charge (Qg) (Max) @ Vgs | 40nC @ 10V |
| Drain to Source Voltage (Vdss) | 40V |
| Input Capacitance (Ciss) (Max) @ Vds | 2350pF @ 25V |
| Current - Continuous Drain (Id) @ 25°C | 30A (Tc) |
