SSF6602
Good-Ark Semiconductor
Package: Cut Tape (CT)
Description: MOSFET, N+P, DUAL, 3.5 -2.7A, 30
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Grade | - |
|---|---|
| Technology | MOSFET (Metal Oxide) |
| FET Feature | - |
| Part Status | Active |
| Power - Max | 1.2W (Ta) |
| Configuration | N and P-Channel Complementary |
| Mounting Type | Surface Mount |
| Qualification | - |
| Package / Case | SOT-23-6 |
| Vgs(th) (Max) @ Id | 2.2V @ 250μA, 2.5V @ 250μA |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Rds On (Max) @ Id, Vgs | 58mOhm @ 3.5A, 10V, 100mOhm @ 2.7A, 10V |
| Supplier Device Package | SOT-23-6L |
| Gate Charge (Qg) (Max) @ Vgs | 5nC @ 10V |
| Drain to Source Voltage (Vdss) | 30V |
| Input Capacitance (Ciss) (Max) @ Vds | 210pF @ 15V, 199pF @ 15V |
| Current - Continuous Drain (Id) @ 25°C | 3.5A (Ta), 2.7A (Ta) |
