TSM098NM10CP ROG
Taiwan Semiconductor Corporation
Package: Cut Tape (CT)
Description: 100V, 49A, SINGLE, N-CHANNEL LOW
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Grade | Automotive |
|---|---|
| FET Type | N-Channel |
| Vgs (Max) | ±20V |
| Technology | MOSFET (Metal Oxide) |
| FET Feature | - |
| Part Status | Active |
| Mounting Type | Surface Mount |
| Qualification | AEC-Q101 |
| Package / Case | TO-252-3, DPAK (2 Leads + Tab), SC-63 |
| Vgs(th) (Max) @ Id | 3.8V @ 250μA |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Rds On (Max) @ Id, Vgs | 9.8mOhm @ 20A, 10V |
| Power Dissipation (Max) | 46W (Tc) |
| Supplier Device Package | TO-252A |
| Gate Charge (Qg) (Max) @ Vgs | 26 nC @ 10 V |
| Drain to Source Voltage (Vdss) | 100 V |
| Input Capacitance (Ciss) (Max) @ Vds | 1535 pF @ 50 V |
| Drive Voltage (Max Rds On, Min Rds On) | 10V |
| Current - Continuous Drain (Id) @ 25°C | 49A (Tc) |
