VS-40MT120PHAPBF
Vishay General Semiconductor - Diodes Division
Package: Tube
Description: MTP - HALF BRIDGE IGBT
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Input | Standard |
|---|---|
| IGBT Type | Trench Field Stop |
| Part Status | Active |
| Power - Max | 305 W |
| Configuration | Half Bridge |
| Mounting Type | Through Hole |
| NTC Thermistor | No |
| Package / Case | 12-MTP Module |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Supplier Device Package | 12-MTP |
| Vce(on) (Max) @ Vge, Ic | 2.65V @ 15V, 40A |
| Current - Collector (Ic) (Max) | 75 A |
| Input Capacitance (Cies) @ Vce | 3.2 nF @ 25 V |
| Current - Collector Cutoff (Max) | 50 μA |
| Voltage - Collector Emitter Breakdown (Max) | 1200 V |
