VS-GT100TS065S
Vishay General Semiconductor - Diodes Division
Package: Box
Description: MODULES IGBT - IAP IGBT
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Input | Standard |
|---|---|
| IGBT Type | Trench |
| Part Status | Active |
| Power - Max | 517 W |
| Configuration | Half Bridge Inverter |
| Mounting Type | Chassis Mount |
| NTC Thermistor | No |
| Package / Case | Module |
| Operating Temperature | -40°C ~ 175°C (TJ) |
| Supplier Device Package | INT-A-PAK IGBT |
| Vce(on) (Max) @ Vge, Ic | 1.32V @ 15V, 100A |
| Current - Collector (Ic) (Max) | 247 A |
| Current - Collector Cutoff (Max) | 100 μA |
| Voltage - Collector Emitter Breakdown (Max) | 650 V |
