XP6932MT
YAGEO XSemi
Package: Tape & Reel (TR)
Description: MOSFET 2N-CH 30V 14.2A 8PMPAK
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Grade | - |
|---|---|
| Technology | MOSFET (Metal Oxide) |
| FET Feature | - |
| Part Status | Active |
| Power - Max | 1.78W (Ta), 2.08W (Tc) |
| Configuration | 2 N-Channel (Dual) Asymmetrical |
| Mounting Type | Surface Mount |
| Qualification | - |
| Package / Case | 8-PowerLDFN |
| Vgs(th) (Max) @ Id | 2.2V @ 250μA |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Rds On (Max) @ Id, Vgs | 5.5mOhm @ 14A, 10V, 2.5mOhm @ 20A, 10V |
| Supplier Device Package | 8-PMPAK (5x6) |
| Gate Charge (Qg) (Max) @ Vgs | 30.4nC @ 10V, 64nC @ 10V |
| Drain to Source Voltage (Vdss) | 30V |
| Input Capacitance (Ciss) (Max) @ Vds | 1712pF @ 15V, 3920pF @ 15V |
| Current - Continuous Drain (Id) @ 25°C | 14.2A (Ta), 28A (Tc), 22.9A (Ta), 40A (Tc) |
