2N2270 TIN/LEAD
Central Semiconductor Corp
Package: Box
Description: 45V 1A 1W TH TRANSISTOR-SMALL SI
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Grade | - |
|---|---|
| Part Status | Active |
| Power - Max | 1 W |
| Mounting Type | Through Hole |
| Qualification | - |
| Package / Case | TO-205AD, TO-39-3 Metal Can |
| Transistor Type | NPN |
| Operating Temperature | -65°C ~ 200°C (TJ) |
| Frequency - Transition | 100MHz |
| Supplier Device Package | TO-39 |
| Vce Saturation (Max) @ Ib, Ic | 900mV @ 15mA, 150mA |
| Current - Collector (Ic) (Max) | 1 A |
| Current - Collector Cutoff (Max) | 50nA |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 50 @ 150mA, 10V |
| Voltage - Collector Emitter Breakdown (Max) | 45 V |
