2SC3585-T1B-A
Renesas Electronics Corporation
Package: Bulk
Description: RF TRANS NPN 10V 10GHZ SOT-23-3
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Gain | 9dB |
|---|---|
| Part Status | Obsolete |
| Power - Max | 200mW |
| Mounting Type | Surface Mount |
| Package / Case | TO-236-3, SC-59, SOT-23-3 |
| Transistor Type | NPN |
| Operating Temperature | 150°C (TJ) |
| Frequency - Transition | 10GHz |
| Supplier Device Package | SOT23-3 (TO-236) |
| Noise Figure (dB Typ @ f) | 1.8dB @ 2GHz |
| Current - Collector (Ic) (Max) | 35mA |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 50 @ 10mA, 6V |
| Voltage - Collector Emitter Breakdown (Max) | 10V |
