2SC3775-3-TB-E
Sanyo
Package: Bulk
Description: RF TRANS NPN 12V 5GHZ 3-CP
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Gain | 14dB |
|---|---|
| Part Status | Active |
| Power - Max | 250mW |
| Mounting Type | Surface Mount |
| Package / Case | TO-236-3, SC-59, SOT-23-3 |
| Transistor Type | NPN |
| Operating Temperature | 150°C (TJ) |
| Frequency - Transition | 5GHz |
| Supplier Device Package | 3-CP |
| Noise Figure (dB Typ @ f) | 1.5dB @ 900MHz |
| Current - Collector (Ic) (Max) | 100mA |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 60 @ 20mA, 10V |
| Voltage - Collector Emitter Breakdown (Max) | 12V |
