2SC6024-TL-E
onsemi
Package: Bulk
Description: RF TRANS NPN 3.5V 14GHZ 3-SSFP
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Gain | 9dB ~ 10.5dB |
|---|---|
| Part Status | Obsolete |
| Power - Max | 120mW |
| Mounting Type | Surface Mount |
| Package / Case | 3-SMD, Flat Leads |
| Transistor Type | NPN |
| Frequency - Transition | 14GHz |
| Supplier Device Package | 3-SSFP |
| Noise Figure (dB Typ @ f) | 1.2dB @ 2GHz |
| Current - Collector (Ic) (Max) | 35mA |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 80 @ 15mA, 3V |
| Voltage - Collector Emitter Breakdown (Max) | 3.5V |
