BC394 TIN/LEAD
Central Semiconductor Corp
Package: Box
Description: 180V 100MA .4W TH TRANSISTOR-SMA
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Grade | - |
|---|---|
| Part Status | Active |
| Power - Max | 400 mW |
| Mounting Type | Through Hole |
| Qualification | - |
| Package / Case | TO-206AA, TO-18-3 Metal Can |
| Transistor Type | NPN |
| Operating Temperature | -65°C ~ 200°C (TJ) |
| Frequency - Transition | 50MHz |
| Supplier Device Package | TO-18 |
| Vce Saturation (Max) @ Ib, Ic | 300mV @ 1mA, 10mA |
| Current - Collector (Ic) (Max) | 100 mA |
| Current - Collector Cutoff (Max) | 50nA (ICBO) |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 30 @ 10mA, 10V |
| Voltage - Collector Emitter Breakdown (Max) | 180 V |
