BFG310W/XR,115
NXP Semiconductors
Package: Bulk
Description: RF TRANS NPN 6V 14GHZ CMPAK-4
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Gain | 18dB |
|---|---|
| Part Status | Obsolete |
| Power - Max | 60mW |
| Mounting Type | Surface Mount |
| Package / Case | SC-82A, SOT-343 |
| Transistor Type | NPN |
| Operating Temperature | 175°C (TJ) |
| Frequency - Transition | 14GHz |
| Supplier Device Package | CMPAK-4 |
| Noise Figure (dB Typ @ f) | 1dB @ 2GHz |
| Current - Collector (Ic) (Max) | 10mA |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 60 @ 5mA, 3V |
| Voltage - Collector Emitter Breakdown (Max) | 6V |
