DTA114YE
Shenzhen Slkormicro Semicon Co., Ltd.
Package: Cut Tape (CT)
Description: 68@5MA,5V 150MW 100MA 50V SOT-52
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Grade | - |
|---|---|
| Part Status | Active |
| Power - Max | 150 mW |
| Mounting Type | Surface Mount |
| Qualification | - |
| Package / Case | SOT-523 |
| Transistor Type | NPN - Pre-Biased |
| Resistor - Base (R1) | 10 kOhms |
| Frequency - Transition | 250 MHz |
| Supplier Device Package | SOT-523 |
| Vce Saturation (Max) @ Ib, Ic | 300mV @ 250μA, 5mA |
| Current - Collector (Ic) (Max) | 100 mA |
| Current - Collector Cutoff (Max) | 500nA |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 68 @ 5mA, 5V |
| Voltage - Collector Emitter Breakdown (Max) | 50 V |
