LSK489 SOT-23 6L ROHS
Linear Integrated Systems, Inc.
Package: Tape & Reel (TR)
Description: JFET 2N-CH 60V SOT23-6
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| FET Type | 2 N-Channel (Dual) |
|---|---|
| Part Status | Active |
| Power - Max | 500 mW |
| Mounting Type | Surface Mount |
| Package / Case | SOT-23-6 |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Supplier Device Package | SOT-23-6 |
| Voltage - Breakdown (V(BR)GSS) | 60 V |
| Voltage - Cutoff (VGS off) @ Id | 1.5 V @ 1 nA |
| Current - Drain (Idss) @ Vds (Vgs=0) | 2.5 mA @ 15 V |
| Input Capacitance (Ciss) (Max) @ Vds | 8pF @ 15V |
