MCH4013-TL-E
onsemi
Package: Tape & Reel (TR)
Description: RF TRANS NPN 3.5V 22.5GHZ 4-MCPH
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Gain | 16dB |
|---|---|
| Part Status | Obsolete |
| Power - Max | 50mW |
| Mounting Type | Surface Mount |
| Package / Case | SOT-343F |
| Transistor Type | NPN |
| Operating Temperature | 150°C (TJ) |
| Frequency - Transition | 22.5GHz |
| Supplier Device Package | 4-MCPH |
| Noise Figure (dB Typ @ f) | 1.5dB @ 2GHz |
| Current - Collector (Ic) (Max) | 15mA |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 70 @ 5mA, 1V |
| Voltage - Collector Emitter Breakdown (Max) | 3.5V |
