MRF16006
MACOM Technology Solutions
Package: Tray
Description: RF TRANS NPN 55V 395C-01
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Gain | 7.4dB |
|---|---|
| Part Status | Active |
| Power - Max | 6W |
| Mounting Type | Chassis Mount |
| Package / Case | 395C-01 |
| Transistor Type | NPN |
| Frequency - Transition | - |
| Supplier Device Package | 395C-01, Style 2 |
| Noise Figure (dB Typ @ f) | - |
| Current - Collector (Ic) (Max) | 1A |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 20 @ 200mA, 5V |
| Voltage - Collector Emitter Breakdown (Max) | 55V |
