MT3S111TU,LF
Toshiba Semiconductor and Storage
Package: Tape & Reel (TR)
Description: RF TRANS NPN 6V 10GHZ UFM
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Gain | 12.5dB |
|---|---|
| Part Status | Obsolete |
| Power - Max | 800mW |
| Mounting Type | Surface Mount |
| Package / Case | 3-SMD, Flat Leads |
| Transistor Type | NPN |
| Operating Temperature | 150°C (TJ) |
| Frequency - Transition | 10GHz |
| Supplier Device Package | UFM |
| Noise Figure (dB Typ @ f) | 0.6dB ~ 0.85dB @ 500MHz ~ 1GHz |
| Current - Collector (Ic) (Max) | 100mA |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 200 @ 30mA, 5V |
| Voltage - Collector Emitter Breakdown (Max) | 6V |
