MT3S113(TE85L,F)
Toshiba Semiconductor and Storage
Package: Cut Tape (CT)
Description: RF TRANS NPN 5.3V 12.5GHZ S MINI
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Gain | 11.8dB |
|---|---|
| Part Status | Obsolete |
| Power - Max | 800mW |
| Mounting Type | Surface Mount |
| Package / Case | TO-236-3, SC-59, SOT-23-3 |
| Transistor Type | NPN |
| Operating Temperature | 150°C (TJ) |
| Frequency - Transition | 12.5GHz |
| Supplier Device Package | S-Mini |
| Noise Figure (dB Typ @ f) | 1.45dB @ 1GHz |
| Current - Collector (Ic) (Max) | 100mA |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 200 @ 30mA, 5V |
| Voltage - Collector Emitter Breakdown (Max) | 5.3V |
