MUR3065BL-BP
MCC (Micro Commercial Components)
Package: Tube
Description: ULTRA FAST RECOVER RECTIFIER 650
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Grade | - |
|---|---|
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Technology | Standard |
| Part Status | Active |
| Mounting Type | Through Hole |
| Qualification | - |
| Package / Case | TO-247-2 |
| Capacitance @ Vr, F | 180pF @ 4V, 1MHz |
| Supplier Device Package | TO-247AD |
| Reverse Recovery Time (trr) | 40 ns |
| Current - Reverse Leakage @ Vr | 10 μA @ 650 V |
| Voltage - DC Reverse (Vr) (Max) | 650 V |
| Current - Average Rectified (Io) | 30A |
| Operating Temperature - Junction | -55°C ~ 175°C |
| Voltage - Forward (Vf) (Max) @ If | 2.4 V @ 30 A |
